  usbasp_single_side.t3001.zip
by Thomas Fischl
Single-Side PCB, TARGET 3001! layout file
Size: 90x40 mm (optimized for case Hammond 1591ATBU)

  lv_usbasp.tar.gz
by Pawel Szramowski (11/2007)
With Low-voltage front-end.
Single-Side PCB, EAGLE layout files, some SMD components

   by Bernhard Walle
Double-Side PCB, EAGLE layout files, part list with order numbers for Reichelt.de and Conrad.de
Size: optimized for case Hammond 1591ATBU

  http://thomaspfeifer.net/atmel_usb_programmer.htm
by Thomas Pfeifer
Single-Side PCB, PDF layout files, SMD components

   by Tomasz Ostrowski
Single-Side PCB, PDF and EPS layout files, only four 0805 SMD parts, rest discrete components

  USBasp_CH.zip
by Christian Heigemeyr
Single-Side PCB, with some SMD 0805 components, PDF-files
With additional buttons for reset and disconnection of the target

  USBasp.sch, USBasp.pcb
ComponentSide.pdf, TopSide.pdf, Schematics.pdf
by Zhurov Pavel
Single-Side PCB, P-CAD 2002 format and PDF files
Crosspiece TXD and RXD are added for the ISP connector

  usbasp_gr.rar
by J.A. de Groot
The board is single sided (EAGLE format), measures 3 by 8 cm and uses only regular components.

  usbasb_mg.zip
by Matthias Görner
Single-Side PCB, eagle-format, with PS/PDF-files
integrated sockets for target chips ATmega8 and ATmega32

  Tarball with layout
by Hannes Östlund
Doubleside-Side PCB, SMD components, very small

   by Sergiy Bogdancev (01/2010)
3.3V version, ATMega48 only. Single-side PCB, ExpressPCB layout format + socket board for varies AVRs. Without future serial interface, chip initially must be programmed with another programmer.

  Eaglefiles (sch/brd) and CAD case design (dxf)
by Hans Hafner, HTL Mössingerstrasse-Klagenfurt, Österreich, hans.hafner (at) htl-klu (dot) at
(01/2010)
CNC-milled case (DXF file available), Eagle layout, only a few SMD parts


  Different USBasp versions: Easy to built non-smd, smd version and a very small USBasp
by Sven Hedin (01/2011)
Eagle files available.

  USB Key AVR Programmer
by Fabio Baltieri (09/2011)
Very small USB key like dimensions. SMD parts.

  AVR ISP Programmer
by Jaroslav Vadel (04/2012)
Small programmer. SMD parts.

  Target project and PDFs (layout/schematics)
by Marius Schäfer (09/2013)

  tinyUSBboard with USBasp-compatible firmware
by Stephan Bärwolf (04/2014)

   USBasp on breadboard with socket for controller daughter boards.
by Fabian Hummel (11/2018)

   Tjaart van Aswegen designed an SMD board: DIP TRACE and GERBER files.
by Tjaart van Aswegen (09/2019)

   Feature rich (e.g. different voltage levels, integrated USB to serial converter, USB-C connector) USBasp compatible design. AVR Programmer Github project.
by Brian Pepin (12/2019)

   USBasp with ZIF socket and through hole components. KiCad design on Github
by Bruno (04/2020)

   USBasp board with additional 6pin header and selectable target supply (3.3V/off/5.0V).
by Marty E. (10/2020)

   John included a 40 pin universal socket which takes 8, 14, 20 and 28 pin devices. He also added a versatile crystal oscillator with outputs of 1, 2, 4, 8 and 16 Mhz to clock the chips. There is also the standard 6pin ICSP connector and a user led connected to the MOSI pin.
by John P. (11/2020)
